Polcd 1.69 Inch TFT Multi Capacitive Touch Screen 4 Line SPI 240x280 IPS Lcd

Brand Name : Polcd

Model Number : P169H002-CTP

Certification : RoHS, ISO9001

Place of Origin : Shenzhen, China

MOQ : 1 piece

Price : Please contact us for latest price

Payment Terms : T/T, L/C, Credit card, PayPal, D/A, D/P, Western Union, MoneyGram

Supply Ability : 25,000 PCS per day

Delivery Time : 1-7 working days

Packaging Details : FCL size: 40*30*20cm / Sample Packaging: 20*18*13cm

Size (inch) : 1.69

Resolution : 240*280

Brightness (cd/m²) : 300

Interface : 4 Line SPI

Driver Ic : ST7789V

Contrast Ratio : 1000:1

Contact Now

New published LCD Touch Panel for commercial and industrial use. Screen size is 1.69 inch. A very common and hot selling size for small size TFT display. Improve your product design by adding our 240 * 280 resolution product. 300 nits allow this lcd to work well indoors.

P/N P169H002-CTP
Size(inch) 1.69
Resolution 240*280
Active Area(mm) 27.97*32.63
Pixel pitch(um) 116.55*116.55
Outline Dimension(mm) 33.13*41.13*3.61
Pixel arrangement RGB Vertical Stripe
Display Mode Normally Black
Viewing Angle ALL
Display colors 262K
Brightness
(cd/m²)		 300
Contrast Ratio 1000:1
Interface 4 Line SPI
Back-light LED Side-light type
Driver Ic ST7789V
Operation Temperature(°C) -20~70
Storage Temperature(°C) -30~80
Response time(ms) 35
Pin Number 18

The Interface of this LCD is 4 Line SPI . We can also customize other types of interfaces and FPCs for you. ST7789V is the driver IC of the tft lcd. THE lowest operating temperature can reach -20°C (-4°F) and highest is 70°C (158°F).

Polcd 1.69 Inch TFT Multi Capacitive Touch Screen 4 Line SPI 240x280 IPS Lcd

Polcd 1.69 Inch TFT Multi Capacitive Touch Screen 4 Line SPI 240x280 IPS Lcd
